    Cebora Power Rod 1840

    8026100 - Cebora Power Rod 1840 Welder including 4/3M Arc Lead Set
    SKU: 201502
    Please give us a brief description of your intended application (we may have a better solution.)

    The Cebora Power Rod 1840 welding machine is suitable for MMA welding aluminium and stainless, using all rutile basic electrodes.  Has a current adjustment range of 10A – 180A and high duty cycle of 40% @ 180A, 60% @150A and 100% @ 120A making it suitable for use in the most extreme conditions.  The IP23 S protection degree makes it possible to use the power source outdoor.

    The Cebora Power Rod 1840 power source is equipped with thermostatic protection.  The PFC system assures a substantial energy saving and makes it possible to use the power source with a mains fuse of 16A (slow blow). It also allows to get a wide tolerance on the supply voltage (+15% / -20%).

    Weighing only 9.5 kg the Power Rod 1840 is a portable machine which can be operated using a 16A mains fuse power source.

    Can weld electrodes up to Ø 4.

    Products specifications
    Single phase input230V 50/60 Hz + 15% / -20%
    Fuse rating (slow blow)16 A
    Input Power6,0 KVA 40% 4,7 KVA 60% 3,6 KVA 100%
    Current adjustment range10A ÷ 180A
    Duty Cycle (10 min.40°C) 180A 40% 150A 60%120A 100%
    Electrodes that can be usedØ 1,5 ÷ 4,0
    Protection classIP 23 S
    Weight9,5 Kg
    Dimension(L x W x H)172x420x340
    Write your own review
    • Product can be reviewed only after purchasing it
    • Only registered users can write reviews
    *
    *
    • Bad
    • Excellent

    The Cebora Power Rod 1840 welding machine is suitable for MMA welding aluminium and stainless, using all rutile basic electrodes.  Has a current adjustment range of 10A – 180A and high duty cycle of 40% @ 180A, 60% @150A and 100% @ 120A making it suitable for use in the most extreme conditions.  The IP23 S protection degree makes it possible to use the power source outdoor.

    The Cebora Power Rod 1840 power source is equipped with thermostatic protection.  The PFC system assures a substantial energy saving and makes it possible to use the power source with a mains fuse of 16A (slow blow). It also allows to get a wide tolerance on the supply voltage (+15% / -20%).

    Weighing only 9.5 kg the Power Rod 1840 is a portable machine which can be operated using a 16A mains fuse power source.

    Can weld electrodes up to Ø 4.

    Products specifications
    Single phase input230V 50/60 Hz + 15% / -20%
    Fuse rating (slow blow)16 A
    Input Power6,0 KVA 40% 4,7 KVA 60% 3,6 KVA 100%
    Current adjustment range10A ÷ 180A
    Duty Cycle (10 min.40°C) 180A 40% 150A 60%120A 100%
    Electrodes that can be usedØ 1,5 ÷ 4,0
    Protection classIP 23 S
    Weight9,5 Kg
    Dimension(L x W x H)172x420x340
