ETC PH700 Supradur V1000

Brand: ETC
SKU: ETCPH70032
Hardfacing
Select the size you require using the drop down box below.

3.2mm x 450mm long, 1.8kg pack (25pc)
4.0mm x 450mm long, 1.6kg pack (15pc)
$ 68 .70 excl GST
$ 79.00 Incl GST
*
*
Please give us a brief description of your intended application (we may have a better solution.)
Call Us- 0800 699 353
Take advantage of our bulk buy price breaks often related to packet / outer ctn quantities, and save yourself $$$
Diameter Options: 3.2mm x 450mm long, 1.8kg pack (25pc)
Quantity
0+
Price
$75.50
Diameter Options: 4.0mm x 450mm long, 1.6kg pack (15pc)
Quantity
0+
Price
$68.70

Product Overview

ETC PH700 SUPRADUR V1000 is a thick rutile coated high-efficiency MMA electrode giving 160% recovery.
The weld microstructure is a hypereutectic stainless chromium hard alloy, used for hard facing against abrasion by mineral particles not resistant to impact and shock, the deposit is only machinable by grinding.
Smooth, regular weld beads are deposited with only minimum penetrations. The hardness cracks which typically appear in this weld metal are not detrimental to resistance against mineral abrasion.
When welding sensitive base materials a buffer layer deposited with SUPERCHROMAX N is required.
Typical applications include hard facing subject to mineral abrasion, e.g. by sand gravel, coal, soil, clay and related minerals used in ceramics, cement and concrete building materials and mining.

Click here to download a full specification sheet.

Select the size you require using the drop down box above left

  • 3.2mm x 450mm long, 1.8kg pack (25pc)
  • 4.0mm x 450mm long, 1.6kg pack (15pc)

Specifications

Products specifications
25pc3.2mm x 450mm long, 1.8kg pack
15pc4.0mm x 450mm long, 1.6kg pack
BrandETC Model

ETC PH700 SUPRADUR V1000 is a thick rutile coated high-efficiency MMA electrode giving 160% recovery.
The weld microstructure is a hypereutectic stainless chromium hard alloy, used for hard facing against abrasion by mineral particles not resistant to impact and shock, the deposit is only machinable by grinding.
Smooth, regular weld beads are deposited with only minimum penetrations. The hardness cracks which typically appear in this weld metal are not detrimental to resistance against mineral abrasion.
When welding sensitive base materials a buffer layer deposited with SUPERCHROMAX N is required.
Typical applications include hard facing subject to mineral abrasion, e.g. by sand gravel, coal, soil, clay and related minerals used in ceramics, cement and concrete building materials and mining.

Click here to download a full specification sheet.

Select the size you require using the drop down box above left

  • 3.2mm x 450mm long, 1.8kg pack (25pc)
  • 4.0mm x 450mm long, 1.6kg pack (15pc)
Products specifications
25pc3.2mm x 450mm long, 1.8kg pack
15pc4.0mm x 450mm long, 1.6kg pack
BrandETC Model
