MOSA DSP500/16 PS Engine Driven Welder

Brand: Mosa
SKU: 203353
Please give us a brief description of your intended application (we may have a better solution.)
Call Us- 0800 699 353

Product Overview

The MOSA DSP500/16 PS Engine Driven Welder is a multi process welder/generator that has the option of five different welding options, chosen by a rotary selector. Lift Arc Tig, Arc (3 programmes) and Mig welding. Thgis welder generator incorporates DSP function which is a digital signal processor whereby the regulation of the welding parameters is performed by digital technique. This is due to the ''chopper system'' which operates at a high frequency and allows superior welding performance to be maintained compared to more conventional techniques at a lower frequency.

Key Features:

- Engine Perkins 404C 22G, water cooled, diesel

- Alternator Mosa, asynchronous, brushless

- Silenced

- Max welding current: 500A

- Welding processes: CC stick, TIG lift-arc, CV wire MIG

- Auxiliary output: CEE socket standard: 1x 32A 400V; 1x 32A 230V; 1x 16A 110V; 1x 32A 110V

Specifications

Products specifications
Current range10 ÷ 500A
Duty Cycle500A - 35%, 450 A - 60%, 400A - 100%
Open circuit voltage62 V
Dry weight750 kg
Measured acoustic power LwA (pressure LpA)91 dB(A) (66 dB(A) @ 7 m)
Guaranteed acoustic power LwA (pressure LpA)92 dB(A) (67 dB(A) @ 7 m)
Cylinders / Displacement4/ 2216 cm3
Speed1500 rpm
Dimension1720x980x1110 mm

The MOSA DSP500/16 PS Engine Driven Welder is a multi process welder/generator that has the option of five different welding options, chosen by a rotary selector. Lift Arc Tig, Arc (3 programmes) and Mig welding. Thgis welder generator incorporates DSP function which is a digital signal processor whereby the regulation of the welding parameters is performed by digital technique. This is due to the ''chopper system'' which operates at a high frequency and allows superior welding performance to be maintained compared to more conventional techniques at a lower frequency.

Key Features:

- Engine Perkins 404C 22G, water cooled, diesel

- Alternator Mosa, asynchronous, brushless

- Silenced

- Max welding current: 500A

- Welding processes: CC stick, TIG lift-arc, CV wire MIG

- Auxiliary output: CEE socket standard: 1x 32A 400V; 1x 32A 230V; 1x 16A 110V; 1x 32A 110V

Products specifications
Current range10 ÷ 500A
Duty Cycle500A - 35%, 450 A - 60%, 400A - 100%
Open circuit voltage62 V
Dry weight750 kg
Measured acoustic power LwA (pressure LpA)91 dB(A) (66 dB(A) @ 7 m)
Guaranteed acoustic power LwA (pressure LpA)92 dB(A) (67 dB(A) @ 7 m)
Cylinders / Displacement4/ 2216 cm3
Speed1500 rpm
Dimension1720x980x1110 mm
