* Three Phase, 400V Input Power
* 40 - 350A DC Welding Output
* 4 Roller, Separate Wire Feeder
* Thermostatic Protection
* Stepped Regulation of ARC Voltage
* Special protection device for motor generator use
* Specifically for industrial welding of steel, stainless steel, high tensile steels and aluminium
* Two Year Warranty
Products specifications
Three phase main voltage | 230/400 V |
Mains Frequency | 50/60 Hz |
Current range | 40-350 A |
Max Current DC | 350 @ 35% A |
DC Current | 260A |
Max no Load Voltage | 43 V |
Max Absorbed power | 15 kW |
Absorbed power at 60% | 8.5 kW |
Power Factor | 0.9 |
Adjustment position | 18 |
Steel welding wire Diameter | 0.6- 1.6 mm |
Inox welding wire Diameter | 0.8- 1.6mm |
Protection degree | IP22 |
Weight | 101kg |
Dimensions | 89x45.3x128.5 |
