Dimensions / 380x155x260mm |
Weight / 7 kg |
Input Power Supply / 230V AC 10A 50/60Hz |
Input Power Tolerance / +/-15% |
Maximum Input Current / 20A |
Rated Input Power Capacity / 7.9KW |
No Load Voltage (V) / 360V |
Plasma Output Current / 10-35A |
Duty Cycle / 60%@25A, 100%@20A |
Plasma Severance Cut Capacity Carbon Steel / 10mm |
Insulation Class / IP23, H |
Power Efficiency / 85% |
Power Factor / 0.93 |
Postflow Time / 15s |
Warranty / 18 months *with product registration |
