Input voltages
(± 10%) | CSA 200 – 240 V, 1-PH, 50-60 Hz OR 480 V, 3-PH, 50-60 Hz1 CE/CCC 230 V, 1-PH, 50-60 Hz OR 400 V, 3-PH, 50-60 Hz |
Input current
@ 6.5 kW | CSA 200 - 240 V, 1-PH, 39/32 A OR 480 V, 3-PH, 9.4 A1 CE/CCC 230 V, 1-PH, 50-60 Hz OR 400 V, 3-PH, 50-60 Hz |
Output current | 10–45 A |
Rated output voltage | 145 VDC |
Duty cycle
@ 40° C (104° F) | CSA 50% @ 45 A, 200 – 240 V, 1-PH 60% @ 41 A, 200 – 240 V, 1-PH 100% @ 32 A, 200 – 240 V, 1-PH 50% @ 45 A, 480 V, 3-PH 60% @ 41 A, 480 V, 3-PH 100% @ 32 A, 480 V, 3-PH |
Open circuit voltage (OCV) | 275 VDC (200 - 240 V, CSA/CE/CCC and 480 V, CSA) 265 VDC (400 V CE/CCC) |
Weight with 6.1 m (20') torch | CSA 14 kg (31 lbs.) |
Gas Supply | Cutting: air (clean, dry and oil-free), nitrogen, F5 Gouging: air (clean, dry and oil-free), nitrogen, F5 Marking: air (clean dry and oil-free) argon |
Recommended
gas inlet
flow rate / pressure | 188 I/min (400 scfh) @ 5,9 bar (90 psi) |
Input power cable length | 3 m (10') |
Power supply type | Inverter – IGBT |
Engine drive requirement | 12.5 kVA (10 kW) for full 45 A output |
Electrical efficiency | 0.88 |
Recyclability | 1 |
Certifications | yes |
Warranty | Power supply: 3-year Torch: 1-year |
Dimension(L x W x H) | 442 mm (17.4") D; 173 mm (6.8") W; 357 mm (14.1") H |
