Miller Bobcat 250 EFI Petrol Engine Driven Welder

Brand: Miller
SKU: 203503
Please give us a brief description of your intended application (we may have a better solution.)
Call Us- 0800 699 353

Product Overview

The Miller Bobcat 250 EFI Petrol Engine Driven Welder is redesigned so it is quieter, smaller and lighter. It is a rugged welder/generator which is great for stick and flux cored welding, designed for construction or farm use including maintenance and repair operations. Reliable Bobcat engine-driven welding generators are the industry standard for quality and value. Multiprocess weld output, strong generator power, and most important — rated #1 in reliability, make the Bobcat the welding industry’s most popular choice.

Key Features:

- Up to 33% quieter

- Smaller and lighter design

- Faster and easier maintenance with front panel maintenance displays

- AC DC CC CV 11kW

- 9,500 Watts Continuous Power

- Tri-Cor Technology

- Processes: Stick (SMAW), TIG (GTAW), MIG (GMAW), Air Carbon Arc Cutting, Flux-Cored (FCAW)





Specifications

Products specifications
Rated Output:MIG/FCAW 250 A at 28 V, 100% duty cycle MIG/FCAW 275 A at 25 V, 60% duty cycleAC/DC Stick/TIG 250 A at 25 V, 100% duty cycle
Output Power Range:DC TIG/Stick 40 - 250 A AC TIG/Stick 40 - 250 A FCAW/MIG 17 - 28 V
Generator Power:Accu-Rated™ 10,500 Watts Peak 9,500 Watts Continuous
Weight:560 lb (254 kg)
Dimension(L x W x H)H: 33" (838 mm) W: 20" (508 mm) L: 45.5" (1156 mm)
EngineKohler 25 HP at 3600 RPM (LP)
